Operating Weight (kg)
Rated Power (kW)

Utilities

Heavy infrastructure

Quarries & Aggregates
Engine system: Weichai engine,high-pressure common rail, supercharged intercooling, three-stage fuel filtration, strong power, energy-saving and efficient.
Advanced vibration system: Vibration wheel adopts through-axis design, amplitude is stable and consistent,good compaction performance.
Robust structures: Front and rear frame articulated connection, high reliability, small turning radius; Internationally famous brand drive axle, large driving force, smooth running, superior performance and long service life.
Comfortable cabin: Newly upgraded H series cab with beautiful appearance, wide view and comfortable driving experience; The rocker switch has a variety of functions and a reasonable layout; New instrument panel, human-machine interaction interface is vivid, the whole machine status information is simple and obvious.
Easy maintenance: Engine filter is centrally located on one side for easy maintenance; The engine hood is equipped with an electric actuator, which can be opened and closed with one key, a large opening and closing angle for easy maintenance; Fuse control box centrally arranged, easy to do maintenance and repair; Air conditioning filter is outside mounted, easy to remove and clean.
| Operating Weight (kg) | 12000 |
| Rated Power (kW) | 99 |
| Compaction Width (mm) | 2130 |
| Engine Model | WECHAI WP4.6NG135E670 |
| Excitation Force (kN) | 270/163 |
| Steering Angle (°) | ±35 |
| Fuel Tank Capacity(L) | 270 |
| Overall Dimension (L×W×H)(mm) | 5947×2316×3170 |
| Nominal Amplitude (mm) | 1.9/0.95 |
| Min. Turing Radius (mm) | 6210 |
